Photography 101: exposure, aperture, shutter speed, and ISO
Every quality photo begins with exposure. Even if you catch a great subject at the perfect moment with strong framing, everything is lost if you blow the exposure.Photographers who shoot in automatic modeare accustomed to the camera takingcare of all the settings. But, as smart as digital cameras have become, they aren’t perfect. Elevating your picture-taking from good to great requires a general understanding of the three elements of exposure: aperture, shutter speed, and ISO. Understand the interplay between these three elements, andyou will be able to anticipate great photographs, rather than wait for happy coincidences.
The temptation to stick to auto mode is understandable: High-end digital cameras can bedaunting, especially for anyone whose only prior camera was a smartphone. But once you know how a camera’s exposure settings work, a lot of that intimidation should be alleviated. When you have a basic understanding of aperture, shutter speed, and ISO which are also the basics of photography, in general you’re well on your way to mastering your digital camera’s advanced modes, even if you never opened the user manual. (Although, you really should read the manual too.)
There’s a lot of technical mumbo-jumbo that goes into how a digital camera handles exposure, butwe’ll attempt to keep this discussion in plain English as much as possible.
What is aperture?
The aperture is simply a hole within the lens that limitsthe amount of light that can pass through the lens. By changing the aperture value on your camera, you increase or decrease the size of that hole, thereby allowing more or less light into the camera. Aperture is measured in f-stops, such as f/22 and f/4, but here’s the thing: The smaller the f-stop number, the larger the opening, and vice versa. So, when you are adjusting the settings, think of the opposite: If you want less light to enter (small aperture), go for a larger f-stop. How large your lens’ aperture can open will depend on your lens. (Hint: A lens’maximum aperture will be part of its model name, like a 50mm f/1.8 or a 12-120mm f/4.)
Beyond controlling the amount of light, aperture determines an image’s depth of field(DOF). Simply put, DOF is how depth will be in focus within the image. An image with a large DOF will have sharp focus from foreground to background, while a small (or “shallow”) DOF sees the focus concentrated on one particular focus plane, with foreground and background elements blurred away. When thinking about the f-stop, choose a smaller number (larger aperture to let in more light) to achieve a smaller DOF, or a larger number (smaller aperture, less light) to increase DOF.
When would you want to control aperture?The most common examples are portraits and landscapes. Portraits often look more appealing when the subject is separated from the background, which a DOF will achieve. On the other hand, for landscapes we typically want everything to be in sharp focus, from the foliage in the foreground the distant mountains. If you’re not sure how much depth of field you need, the beauty of digital photography is the ability to “guess and check.” Simply take a photo, check it out on the camera’s LCD screen, and either increase or decrease the size of the aperture to get the desired DOF.
Why does shutter speed matter?
Just like the shutters on your windows, a camera’s shutteropens to allow light in. The shutter lives just in front of the imaging sensor (or film, in the old days) and the shutter speed is the amount of time it stays open.Aperture and shutter speed work together: Whereas the aperture determines the amount of light that’s coming through the lens, the shutter determines the length of time the sensor will be exposed to that light. When you setthe shutter speed usuallymeasured in fractions of a second (e.g. 1/30, 1/1,000) you are telling the camera how quickly or slowly to open and close the shutter. A shutter speed of 1/4,000 second is very fast and will let in very little light, while a shutter speed of 1/2 second will let in a lot of light.
In addition to its role in exposure, shutter speed controls how motion is captured by the camera.A fast shutter speed will freeze moving objects in their track, while a slow shutter speed will record the movement, allowing objects to blur. While a certain shutter speed is required to take a steady picture without a tripod, blur isn’t necessarily bad and sharpness isn’t necessarily good. There are many situations when the choice between the two is a creative one, rather than a technical one. For example, imagine a speedingrace car: Some may want a blurry effect to illustrate its motion around the track, while others may want to freeze it to show a specific moment, such as when it crossed the finish line. In the former example, you’ll want to try a slower shutter speed like 1/60, while the latter example would require a speed of 1/1,000 or more.
There are a few things to keep in mind. If you are using a very slow shutter speed, make sure your camera is stabilized on a tripod or other steady surface to prevent camera shake.When hand holding your camera, the slowest shutter speed you can shoot without introducing shake depends on many factors,including the focal length of your lens and whether or not it (or your camera) has image stabilization. Generally speaking, shutter speeds between 1/60 and 1/125 second (or faster) are safe for handheld shots.
What is ISO?
ISO simply stands for International Standards Organization, but its meaning in photography is unique. Also known as “film speed,” it is a rating carried over from the film days, but means the same thing on digital cameras: sensitivity to light. ISO controls how the sensor responds to the light it receives from the shutter and aperture. A high ISO makes it more sensitive to light, whereas a low ISO is less sensitive to light.
Aperture, shutter speed, and ISO all affect exposure in similar ways, but whereas the first two have creative side effects (DOF, motion blur), ISO isn’t so lucky. Generally speaking, you’ll want to keep ISO as low as possible while still achievingthe correct exposure, as increasing the ISO also increases noise.When you hear someone describe a photo as being “too noisy,” ISO is likely to blame. Noise is rarely a creative effect we’re after, and if we are, it’s usually best to add it in post. Sensors also just perform better at low ISO settings, recording better color depth and dynamic range.(In the film days, high ISO films were “grainier.” You can think of “grain” and “noise” as being effectively the same thing.)
In daylightorwell lit scenes, the ISO can be set low, usually around 100 to 400 (ISO is rated in the hundreds, e.g. 100, 200, 400, 800, etc.). In such cases, you can typically rely on just your aperture and shutter speed to dial in a proper exposure. However, in dim lighting, there may be no other option than to increase ISO. Furthermore, if you want both a fast shutter speed and deep depth of field (small aperture), then raising the ISO might be necessary.Many cameras advertise insanely high maximum ISOs, but don’t always believe the marketing hype. Just because a cameracan shoot at ISO 102,400 doesn’t mean you should use it.
Is there a way to shoot in dark settings without raising the ISO? Well, there’s always flash but in general, on-camera flash produces unflattering results.Whether you prefer the look of flash or the look of noise is a choice you may have to make. You can also place the camera on a tripod to allow the use of a slower shutter speed, thereby keeping ISO low. However, if you’re trying to shoot people other other subjects that aren’t perfectly still, this may not be an option. Finally, investing in a lens with a wider maximum aperture might be a good idea, as the kit lenses included with most interchangeable lens cameras have relatively small maximum apertures. But, as evidenced in the photo above, sometimes even an f/1.4 lensisn’t enough to keep the ISO down.
How do aperture, shutter speed, and ISO work together?
As you’ve probably concluded, aperture, shutter speed, and ISO work together to properly expose an image. A change to one will impact the other two. For example, increasing the shutter speed will need to be matched by an increase in ISO or aperture size to maintain the same exposure value. Likewise,decreasing the size of the aperture (selecting a larger f-number) willrequire a faster shutter speed or lower ISO. The basic point here is that selecting an exposure is always an exercise in compromise. In many situations, it may not matter, but in tricky lighting, finding a balance of settings that offers the DOF, motion, and noise levels you want may be a challenge.
If this is sounding complicated, don’t worry: In addition to full automatic and full manual exposure modes, there are “in-between” modes that give you more control while streamlining and simplifying the exposure process. Want to just focus on depth of field?Aperture Priority or Aperture Value mode (A or Av)lets you set the aperture and compensates with the shutter speed automatically. Shutter Priority or Time Value (S or Tv) is the reverse, controlling aperture automatically while letting you manually select a shutter speed. Auto ISO is generally turned on or off independently of exposure mode, and turning it on willremove another step from the equation, but mayinadvertently lead to noisier pictures.
Don’t freak out if this all seems overwhelming. Know that there’s no magic answer to understanding exposure, and even professional photographers constantly play with the settings until they get an image they are happy with. The key is to experiment and not be intimidated.
Key digital photography takeaways
- When it comes to the aperture setting, think of the opposite: a small f-stop number equals a large aperture setting, while the large f-stop number equals a small aperture setting.
- To blur the background of a portrait, choose a large aperture (small f-stop). To keep the entire image in-focus, choose a small aperture setting (large f-stop).
- To “freeze” a moving object, use a fast shutter speed. For a blurring effect, use a slower shutter speed.
- A tripod is handy when shooting images atvery low shutter speeds.
- To reduce noise, try to always keep ISO as low as possible but know you mayhave to raise it in low light settings.
- Changing one setting affects the others. If you are using a slow shutter speed, you’ll likely need to use a smaller aperture to compensate.
- If you don’t mind handing over some control to the camera, choose Aperture Priority mode to only control depth of field or Shutter Priority mode for motion capture.
- There’s no wrong way to take a photo. Experiment with the settings until you get the shot you’re happy with.
